HDL Works IO Checker v2.1 R2 for Windows 英文正式版(電子設計軟體)
破解說明:
關掉主程式,破解檔放置於crack夾內,請將破解檔複製於主程式的安裝目錄內既可破解
內容說明:
驗證在幾分鐘內FPGA的IO引腳PCB和FPGA之間的數百- 當使用大型FPGA在PCB上的FPGA管腳連接
到正確的信號，是一項繁重的任務。 FPGA上的方引腳被分配到頂層的HDL信號在FPGA上實現的
邏輯。 PCB上側引腳連接到適當的網，將它連接到其他元件在PCB上。由於FPGA和PCB的實施往
往是做平行，所使用的信號名稱並不總是相同的。為了使事情更糟的是，它往往是必要的執行
針掉期防止PCB布線問題。這些引腳互換作出FPGA和PCB上。由於這是幾乎總是體力勞動，目前的
設備已超過1500針，容易犯一個錯誤。
英文說明:
Verifying hundreds of FPGA IO pins between PCB and FPGA in minutes
- When using large FPGA's on a PCB making sure that the FPGA pins are
connected to the right signals is a cumbersome task. On the FPGA side
the pins are assigned to the HDL signals that form the toplevel of the
logic implemented on the FPGA. On the PCB side the pins have to be
connected to the proper net that will connect it to other components
on the PCB. Because implementation of FPGA and PCB is often done in
parallel, the signal names used are not always identical. To make
things even worse, it is often necessary to perform pin swaps to
prevent PCB routing problems. These pin swaps have to be made both
on the FPGA and the PCB. As this is almost always manual work, and
current devices have over 1500 pins, a mistake is easily made.
